كتيب

3

GB

65 - 100 cm

Connecting the drain hose

Connect the drain

hose, without bending

it, to a drainage duct

or a wall drain located

at a height between

65 and 100 cm from

the floor;

alternatively, rest

it on the side of

a washbasin or

bathtub, fastening

the duct supplied to

the tap (see figure).

The free end of the

hose should not be

underwater.

! We advise against the use of hose

extensions; if it is absolutely necessary, the

extension must have the same diameter as the

original hose and must not exceed 150 cm in

length.

Electric connection

Before plugging the appliance into the mains

socket, make sure that:

• the socket is earthed and in compliance with

the applicable law;

• the socket is able to sustain the appliance’s

maximum power load indicated on the

Technical Data Plate fixed on the machine;

• the supply voltage is included within the

values indicated on the Technical Data Plate

fixed on the machine.

• the socket is compatible with the washing

machine’s plug. If this is not the case,

replace the socket or the plug.

Your appliance is now supplied with a 13 amp

fused plug it can be plugged into a 13 amp

socket for immediate use. Before using the

appliance please read the instructions below.

WARNING - THIS APPLIANCE MUST BE

EARTHED.

THE FOLLOWING OPERATIONS SHOULD

BE CARRIED OUT BY A QUALIFIED

ELECTRICIAN.

Replacing the fuse:

When replacing a faulty fuse, a 13 amp ASTA

approved fuse to BS 1362 should always be

used, and the fuse cover re-fitted. If the fuse

cover is lost, the plug must not be used until a

replacement is obtained.

Replacement fuse covers:

If a replacement fuse cover is fitted, it must

be of the correct colour as indicated by

the coloured marking or the colour that is

embossed in words on the base of the plug.

Replacements can be obtained directly from

your nearest Service Depot.

Removing the plug:

If your appliance has a non-rewireable

moulded plug and you should wish to re-route

the mains cable through partitions, units etc.,

please ensure that either:

the plug is replaced by a fused 13 ampere

rewireable plug bearing the BSI mark of

approval.

or:

the mains cable is wired directly into a 13

amp cable outlet, controlled by a switch, (in

compliance with BS 5733) which is accessible

without moving the appliance.

Disposing of the plug:

Ensure that before disposing of the plug itself,

you make the pins unusable so that it cannot

be accidentally inserted into a socket.

Instructions for connecting cable to an alternative

plug:

Important: the wires in the mains lead are

coloured in accordance with the following

code:

Green & Yellow Earth

Blue Neutral

Brown Live
