2

GB

! This instruction manual should be kept in a safe

place for future reference. If the washer-dryer is

sold, transferred or moved, make sure that the

instruction manual remains with the machine so

that the new owner is able to familiarise himself/

herself with its operation and features.

! Read these instructions carefully: they contain

vital information relating to the safe installation

and operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the washer-dryer from its packaging.

2. Make sure that the washer-dryer has not been

damaged during the transportation process. If

it has been damaged, contact the retailer and

do not proceed any further with the installation

process.

3 . R e m o v e t h e 4

protective screws (used

during transportation)

and the rubber washer

with the corresponding

spacer, located on

the rear part of the

appliance (see figure).

4. Close off the holes using the plastic plugs

provided.

5. Keep all the parts in a safe place: you will

need them again if the washer-dryer needs to

be moved to another location.

! Packaging materials should not be used as

toys for children.

Levelling

1. Install the washer-dryer on a flat sturdy floor,

without resting it up against walls, furniture

cabinets or anything else.

2. If the floor is not

p e r f e c t l y l e v e l ,

c o m p e n s a t e f o r

any unevenness by

tightening or loosening

the adjustable front

feet (see figure); the

angle of inclination,

measured in relation to

the worktop, must not

exceed 2°.

Levelling the machine correctly will provide it with

stability, help to avoid vibrations and excessive

noise and prevent it from shifting while it is

operating. If it is placed on carpet or a rug, adjust

the feet in such a way as to allow a sufficient

ventilation space underneath the washer-dryer.

Connecting the electricity and

water supplies

Connecting the water inlet hose

1. Connect the supply

pipe by screwing it

to a cold water tap

using a ¾ gas threaded

connection (see figure).

Before performing the

connection, allow the

water to run freely until

it is perfectly clear.

2. Connect the inlet

hose to the washer-

dryer by screwing it

onto the corresponding

wat er inl et of t he

appliance, which is

situated on the top

right-hand side of

the rear part of the

appliance (see figure).

3. Make sure that the hose is not folded over

or bent.

! The water pressure at the tap must fall within

the values indicated in the Technical details table

(see next page).

! If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.

Installation
