05 GB

2.1. ENVIRONMENT THE APPLIANCE

SHOULD BE PLACED

•The appliance must not be placed on a base

•There must be sufficient natural air ventilation in the room for gas

combustion for the appliance to function correctly.

•The air flow should enter through grilled air vents in the outer walls.

•Air grills must have a cross section of 100 cm² for the passage of air and

for appliances with a flame safety device. For appliances with no flame

safety device, this cross section should be 200 cm². (Single or multiple

grills can be used)

Emission of Combustion Gases

•Combustion gases from cooking appliances must be released directly out

of doors or via a hood connected to a chimney or flue (Figure 1)

•If it is impossible to install a hood, an electric extraction fan should be fitted

in a wall or a window opening out of doors (Figure 2)

•Extractor fans should have a capacity of replacing kitchen air 3- 5 times

per hour.

Figure 1 Figure 2

•This grill(s) should be constructed so that it cannot be closed from

either side and positioned preferably near the floor. Grill(s) must not be

placed across the channels through which combustion gases and

exhausted fumes pass.

•If it is impossible to install grilled air vents in the room where the

appliance is installed, the air needed can also be supplied from an

adjacent room providing it is not a bedroom or a room where an air

current could cause danger.

750 mm

400 mm

200 mm 200 mm

20 mm

20 mm

2.2. POSITIONING

This appliance is “Class 2.1”. The appliance has been designed on

the presumption that the adjacent work tops will be no higher than the

cook top surface.

2.3. FEET ADJUSTMENT

•The maximum height of cooker will be 920mm by fixing the adjustable

feet.

Your appliance has adjustable feet at the lower corners of its chassis.

•The feet can be adjusted individually with the aid of a wrench to

guarantee that the oven is perfectly balanced and levelled, so that any

liquids in the pans is horizontal .

2.4. ELECTRICAL CONNECTION

Cookers can be presented with or without enrgy cable. Cable

connection should be done by Autorited service according to

following instructions.

The electrical connection must be made according to the standards

and regulations in force. Before making the electrical connection,

check the following:

•Is the capacity of the electrical connections and safety fuses in the

building sufficient to cope with the load of the appliance? (Check with

the adhesive info label)

•Does the electricity supply line have an earth connection conforming

with the standards in force? A proper earth connection must exist in

your home. If there is not a proper earth connection at your home,

please apply to an authorized technician to deal with this problem.

•Is the socket or the multi-pole switch at a easily reachable point after

the installation of the appliance?

•A plug conforming to standards should be connected to the mains

cable and the cable should be inserted into a safe socket.

•A multi-pole switch must be used between the appliance and the

electricity line if a direct electrical connection to the appliance is

required. (It must comply with standards and be appropriate for the

load)

The green-yellow ground cable must not be interrupted by a switch.

The brown phase cable (from the “L" coded connector of the oven)

must always be connected to the phase line of the mains.

•The power line must be positioned so that it is not exposed to

temperatures higher than 50° C.

•When the power cable must be changed, a cable with a cross section

appropriate to the indicated power must be used. The green-yellow

ground cable should be approximately 2 cm longer than phase and

neutral cables.

•Check the heaters by switching them on for 3 minutes, after having

completed the connection.

•The manufacturer will not accept responsibility for damages

arising due to non-compliance with the safety standards.

•For the direct connection to the fixed wiring, it’s nessessary to provide

means for disconnection from the supply mains having a contact

separation in all poles that provide full disconnection under

overvoltage category III conditions, in accordance with the wiring

rules
