4

EN

LOADING THE RACKS

CAPACITY: 15 standard place-settings

CUTLERY RACK

The third rack was designed to house the

cutlery.

Arrange the cutlery as shown in the gure.

A separate arrangement of the cutlery makes

collection easier after washing and improves

washing and drying performance.

Knives and other utensils with sharp edges

must be positioned with the blades facing

downwards.

The cutlery basket is equipped with two sliding

side trays to make the most of the height of the

space below and enable the loading of high

items into the upper rack.

UPPER RACK

Load delicate and light dishes: glasses, cups, sa-

ucers, low salad bowls.

The upper rack has tip-up supports which can

be used in a vertical position when arranging

tea/ dessert saucers or in a lower position to

load bowls and food containers.

(loading example for the upper rack)

Adjusting the height of the upper rack

The height of the upper rack can be adjusted: a high position to place bulky

crockery in the lower basket and low position to make the most of the tip-up

supports by creating more space upwards and avoiding collision with the

items loaded into the lower rack.

The upper rack is equipped with an Upper Rack height

adjuster (see gure), without pressing the levers, lift it up

by simply holding the rack sides, as soon as the rack is sta-

ble in its upper position. To restore to the lower position,

press the levers A at the sides of the rack and move the

basket downwards.

We strongly recommend that you do not adjust the

height of the rack when it is loaded.

NEVER raise or lower the basket on one side only.

Foldable aps with adjustable position

The side foldable aps can be folded or unfolded

to optimize the arrangement of crockery inside

the rack. Wine glasses can be placed safely in the

foldable aps by inserting the stem of each glass

into the corresponding slots.

Depending on the model:

• to unfold the ap there is needed to slide it up

and rotate or release it from the snaps and pull

it down.

• to fold the ap there is needed to rotate it and

slide ap down or pull it up and attach ap to

the snaps.

LOWER RACK

For pots, lids, plates, salad bowls, cutlery etc. Large plates and lids should ide-

ally be placed at the sides to avoid interferences with the spray arm.

The lower rack has tip-up supports which can be used in a vertical position

when arranging plates or in a horizontal position (lower) to load pans and

salad bowls easily.

(loading example for the lower rack)

POWER CLEAN®

Power Clean® uses the special water jets in the

rear of the cavity to wash more intensively the

highly dirty items. The lower rack has a Space

Zone, special pull-out support in the rear of the

rack that can be used to support frying pans or

baking pans in an upright position, thus taking

up less space.

Placing the pots/casseroles faced to the Power Clean® component please

activate the POWER CLEAN® on the panel.

How to use Power Clean®:

1. Adjust the Power Clean® area G folding

down the rear plate holders to load pots.

2. Load pots and casseroles inclined vertically

in the Power Clean® area. Pots have to be

inclined towards the powerful water jets.

CARE AND MAINTENANCE

CLEANING THE FILTER ASSEMBLY

Regularly clean the lter assembly so that the lters do not clog and that

the waste water ows away correctly.

Using the dishwasher with clogged lters or foreign objects inside the l-

tration system or spray arms may cause unit malfunction resulting in loss of

performance, noisy work or higher resources usage.

The lter assembly consists of three lters which remove food residues

from the washing water and then recirculate the water.

The dishwasher must not be used without lters or if the lter is loose.

At least once per month or after every 30 cycles, check the lter assembly

and if necessary clean it thoroughly under running water, using a non-me-

tallic brush and following the instructions below:

1. Turn the cylindrical lter A in an anti-clockwise direction and pull it out

(Fig 1). It is important when reinstalling the lter that the two trian-

gles shown on the zoom meet.

2. Remove the cup lter B by exerting a slight pressure on the side aps

(Fig 2).

3. Slide out the stainless-steel plate lter C (Fig 3).

4. In case you nd foreign objects (such as broken glass, porcelain,

bones, fruit seeds etc.) please remove them carefully.

5. Inspect the trap and remove any food residues. NEVER REMOVE the

wash-cycle pump protection (shown by an arrow) (Fig 4).

After cleaning the lters, replace the lter assembly and x it in

position correctly; this is essential for maintaining the ecient

operation of the dishwasher.

2

1

4

3

A

A

B

C
