Before to run the descaling phase, the appliance

will check if some residual water is contained into

the boiler, and a Drain cycle could be performed,

if needed. In this case, you will have to empty the

drawer after the Drain cycle, before continuing with

the Descale Phase.

Please note: to ensure that the water is cold, it is not possible

to perform this activity before 30 minutes have elapsed from

the last cycle (or the last time the product was powered).

During this waiting time, the display will show the following

feedback “WATER IS HOT”.

» PHASE 1/2: DESCALING 70 MIN

When display will show <ADD 0.25 L OF SOLUTION>,

please pour the descaling solution in the drawer. For

best results in descaling, we recommend filling the

tank with a solution composed of 75 g of the specific

WPRO product and 250 ml of drinking water. Make

sure the solution dissolves completely in the water

so that no residue remains. WPRO descaler is the

suggested professional product for the maintenance

of the best performance of your steam function in the

oven. For orders and information contact the after

sales service or www.whirlpool.eu. Whirlpool will

not be held responsible for any damage caused by

the use of other cleaning products available on the

market.

1 + +2

= 75 g

250 ml

3

Once the descaling solution is poured inside the

drawer, press

to start the main descaling process.

The descaling phases do not need you to stay in front

of the appliance. After each phase is completed, an

acoustical feedback will be played and the display

will show instructions to proceed with the next

phase.

Once the descaling phase has been completed, the

boiler will be drained: the descaling solution used

during this phase will be poured into the extractable

drawer.

» PHASE 2/2: RINSING (30 min.)

To remove descale residuals from the drawer and the

steam circuit, rinse cycle has to be done. When display

shows <ADD 0.25 L OF WATER> fill the tank with 0,25 L

of drinking water, then press

to start the rinsing. Do

not turn off the oven until all the steps required by the

function have been completed.

When the message “DESCALING COMPLETED” appears

on the display, please press OK to confirm.

Cooking functions cannot be activated during the

cleaning cycle. Please note: A message will be shown

on display, to remind you to execute this operation

regularly.

When Descale procedure is completed, it is suggested

to dry the cavity from potential water residuals. It will

be then possible to use all the steam functions.

Note: during the Descale cycle, some noise could

potentially be heard since the oven pumps are

activated in order to guarantee the optimal descale

efficiency.

Once the maintenance cycle has started, do not remove

the drawer unless requested by the appliance.

. MINUTEMINDER

When the oven is switched off, the display can be

used as a timer. To activate this function, make sure

that the oven is switched off and press

or : The

icon will flash on the display.

Press

or to set the length of time you require and

then press

to activate the timer.

MINUTE-MINDER

An audible signal will sound and the display will

indicate once the minuteminder has finished

counting down the selected time.

Please note: The minuteminder does not activate any of the

cooking cycles. Press

or to change the time set on the

timer.

Once the minuteminder has been activated, you can

also select and activate a function.

Press

to switch on the oven and then select the

function you require.

Once the function has started, the timer will continue

to count down independently without interfering

with the function itself.

Please note: During this phase, it isn’t possible to see the

minuteminder (only the

icon will be displayed), that will

continue counting down in background. To retrieve the

minuteminder screen press

to stop the function that is

currently active.

. KEYLOCK

To lock the keypad, press and hold for at least five

seconds. Do this again to unlock the keypad.

KEYLOCK

Please note: This function can also be activated during

cooking. For safety reasons, the oven can be switched o at

any time by pressing

.
