When requested on the display with ”ADD WATER”

indications, open the drawer by pressing the

tilting cap. Once extracted, open drawer’s lid and

slowly pour in some drinking water until the notch

corresponding to the level requested on the display

(LEVEL 1 - 160 ml or LEVEL 2 - 300 ml, based on

selected function) is reached. In any case, do not

overfill the drawer exceeding the notch indicating

Level 2. Close the drawer by pushing it carefully

towards the panel until completely closed. The

drawer must always remain closed, except for water

filling.

After the first filling, in case of longer cooking cycles,

once water will have ran out, it could be necessary to

add it again, in order to complete the cycle: the oven

will prompt it in case it is needed.

Avoid to fill the drawer when the oven is switched off,

or up to it is requested from the display.

We suggest emptying the drawer after the cooking

steam cycle.

3. START THE FUNCTION

At any time, if the default values are those desired or

once you have applied the settings you require, press

to activate the function.

During the delay phase, by pressing

the oven

will ask if you want to skip this phase, starting

immediately the function.

Please note: Once a function has been selected, the display

will recommend the most suitable level for each function.

At any time you can stop the function that has been

activated by pressing

.

If the oven is hot and the function requires a specific

maximum temperature, a message will shown on

the display. Press

to return to previous screen

and select a different function or wait for a complete

cooling.

4. PREHEATING

Some functions have an oven preheating phase: Once

the function has started, the display indicates that

the preheating phase has been activated.

PREHEATING

Once this phase has finished, an audible signal will

sound and the display will indicate that the oven

has reached the set temperature, requiring to “ADD

FOOD”. At this point, open the door, place the food

in the oven, close the door and start cooking by

pressing

or .

Please note: Placing the food in the oven before preheating

has nished may have an adverse eect on the nal

cooking result. Opening the door during the preheating

phase will stop pause it.

The cooking time does not include a preheating

phase. You can always change the temperature you

want the oven to reach using

or .

5. PAUSE COOKING / TURN OR CHECK FOOD

By opening the door, the cooking will be temporarily

paused through deactivating heating elements.

To resume the cooking, close the door.

Some 6th Sense functions will require the food to be

turned during cooking.

TURN FOOD

An audible signal will sound and the display shows

the action to be done. Open the door, do the action

prompted by the display and close the door, then

press

to continue cooking.

In the same way, at 10% of time before the end of

cooking, the oven prompts you to check the food.

CHECK ON FOOD

An audible signal will sound and the display shows

the action to be done. Check the food, close the door

and press

or to continue cooking.

Please note: Press

to skip these actions. Otherwise, if no

action is done after a certain time the oven will continue

the cooking.

6. END OF COOKING

An audible signal will sound and the display will

indicate that cooking is complete.

END

Press to continue cooking in manual mode

(untimed) or press

to extend the cooking time by

setting a new duration. In both cases, the cooking

parameters will be retained.
