CLEANING AND MAINTENANCE

Make sure that the oven has

cooled down before carrying out

any maintenance or cleaning.

Do not use steam cleaners.

Do not use wire wool, abrasive

scourers or abrasive/corrosive

cleaning agents, as these could

damage the surfaces of the

appliance.

Wear protective gloves.

The oven must be disconnected

from the mains before carrying out

any kind of maintenance work.

EXTERIOR SURFACES

. Clean the surfaces with a damp microfibre cloth.

If they are very dirty, add a few drops of pH-neutral

detergent. Finish off with a dry cloth.

. Do not use corrosive or abrasive detergents. If any of

these products inadvertently comes into contact with

the surfaces of the appliance, clean immediately with a

damp microfibre cloth.

INTERIOR SURFACES

. After every use, leave the oven to cool and then

clean it, preferably while it is still warm, to remove

any deposits or stains caused by food residues To

dry any condensation that has formed as a result of

cooking foods with a high water content, let the oven

to cool completely and then wipe it with a cloth or

sponge.

. Activate the “Smart Clean” function for optimum

cleaning of the internal surfaces.

. Clean the glass in the door with a suitable liquid

detergent.

. The oven door can be removed to facilitate cleaning.

ACCESSORIES

Soak the accessories in a washing-up liquid solution

after use, handling them with oven gloves if they

are still hot. Food residues can be removed using a

washing-up brush or a sponge.

WATER DRAWER MAINTENANCE

Caution: The water drawer is not suitable for

dishwasher use: risk of damage!

At the end of each cooking cycle with steam, after

about 30 min the oven automatically performs a drain

cycle lasting about one minute, thus transferring all

the water in the system to the extractable drawer.

Once completed the auto-drain, proceed as follows:

1. Press the top of the drawer front cap, indicated

with a recess, to pull out the handle

2. Grasp the handle and pull out the water drawer.

3. Remove the lid of the water drawer.

4. Empty the water drawer and clean it.

5. Dry the different components by using a soft cloth.

6. If necessary, allow the drawer to air dry without

closing it with the lid.

7. Replace the water drawer lid.

8. Re-insert the washed and dried removable water

drawer into its housing making sure to push it all

the way down

9. Press the bottom of the drawer front cap to

reposition the handle.

Note: If needed, a manual drain cycle can be performed:

press the Cleaning icon

on the UI panel and by

navigating with the + and - buttons, select the Drain

option and press the icon

to start. The oven will drain

the water in the system, conveying it to the extractable

drawer.

Note: Avoid to leave the water in the system more than 2

days.

Use only room temperature water when filling the

water drawer: hot water may affect the operation of

the steam system. Use only drinking water.

BOILER

To ensure that the oven always works at optimum

performance and to help prevent the build-up of

limescale deposits over time, we recommend using

the “Drain” and “Descale” functions regularly.

After a long period of non-use of the “Forced Air +

Steam” function, it is higly suggested to activate

a cooking cycle with the empty oven by filling

completely the tank.

REPLACING THE LIGHT

1. Disconnect the oven from the power supply.

2. Unscrew the cover from the light, replace the bulb

and screw the cover back on the light.

3. Reconnect the oven to the power supply.

Please note: 40 W/230 ~ V type G9, T300°C halogen bulbs.

The bulb used in the product is specically designed for

domestic appliances and is not suitable for general room

lighting within the home. Light bulbs are available from our

After-sales Service.

- If using halogen bulbs, do not handle them with your

bare hands as your ngerprints could cause damage. Do

not use the oven until the light cover has been retted.
