INSTRUCTION MANUAL
INSTRUCTION
Please read this instruction carefully in order to
use the scale correctly & keep the scale in good
condition.
FEATURES
1. Indicate volume of water and milk
2. Two weight unit systems g/lb:oz convertible
3. Two volume unit systems ml/’oz convertible
4. Low battery power/Overload indication
5. With high precision strain gauge sensor
6. With tare function
7. Auto off
BATTERY
1 pc lithium battery (CR2032)
Please remove the isolation
sheet from battery contact
before use. Please observe the
polarity.
TO REPLACE BATTERY
1. Open battery case cover on
the back of scale.
2. Bend the small black tab
outwards and the battery will
come out. Take note not to
bend the contact.
3. Install new battery by putting one side
of battery beneath the contact and then
pressing down the other side.
LCD
WORKING MODES
UNIT CONVERSION BUTTON
At the bottom of scale, you can
nd a unit conversion button as
shown in picture.
TO CONVERT WEIGHT UNIT
If the scale is with both unit systems of Metric (g,
ml) or Imperial (lb:oz, ’oz), press MODE button
to choose working mode (weight, milk volume,
water volume), then press
unit conversion
button to convert between two systems. Take
the conversion of weight unit for example: (see
g. 1)
* When setting g as weight unit, the default
volume unit is ml;
* When setting lb: oz as weight unit, the default
volume unit is ’oz.
Remark: The unit system of scale depends
on sales destination or the requirement of
distributor.
TO START WEIGHING
A. Place the scale on a solid and at surface.
B. Place bowl (if used) on the scale before
turning on the scale.
C. Press „ON/OFF“ to enter weighing mode.
D. Wait until LCD shows all information.
E. Load weighing object on to start weighing,
LCD wil l show the weight reading.
F. If the weighing object is water or milk, press
MODE button to choose volume mode and
view the volume of weighing object.
(see g. 3)
A. Place the scale on a solid and at surface.
B. Press“ON/OFF“ to turn on the scale.
C. Wait until LCD shows „0“, and press MODE
button to choose „Water“ or „Milk“ mode.
D. Put a liquid container onto the scale platform.
E. Press ZERO button to reset LCD to „0“.
F. Pour liquid (water or milk) into the container,
LCD shows the volume of the liquid.
G. Press MODE button to choose „Weight“
mode and view the weight of liquid.
„ZERO“ OR „TARE“ FUNCTION
To weigh different loads consecutively without
removing loads from the scale. Put rst Load
on the scale, get weight reading. Press ZERO
button to reset the LCD reading to „0“ before
adding next load. You can repeat this operation.
(see g. 4)
LCD will show „0“ each time ZERO is pressed.
Icon „0“ will show on lower left corner of LCD,
indicating „ZERO“ function is active. Max. weight
capacity remains unchanged.
(see g. 5)
LCD will show „0“ each time ZERO is pressed.
Icon „T“ will show on upper left corner of LCD,
indicating „TARE“ function is active. Max. weight
capacity is reduced by total weight of all loads.
By pressing ZERO, you can see the total weight
of all loads on the scale. If you want to weigh
more loads, just press ZERO to reset LCD
reading to ‚0‘ again.
AUTO SHUT OFF
Auto shut-off occurs if display
shows ‚0‘ or shows the same
weight reading for 2 minutes.
MANUAL SHUT OFF
To maximize battery life, always
press ON/OFF again to turn off
the scale after using.
Note: when display shows „0“,
press „ON/OFF“ to turn off the
scale; when display shows weight reading, press
„ON/OFF“ for 3 seconds to turn off the scale.
WARNING INDICATORS
1. Replace new battery.
2. Scale overload. Remove
item to avoid damage. Max.
weight capacity is indicated
on the scale.
CLEANING AND CARE
1. Clean the scale with a slightly damp cloth.
DO NOT immerse the scale in water or use
chemical/abrasive cleaning agents.
2. All plastic parts should be cleaned
immediately after contact with fats, spices,
vinegar and strongly avored/colored foods.
Avoid contact with acids citrus juices.
3. Always use the scale on a hard, at surface.
DO NOT use on carpet.
