English | 7

Bosch Power Tools 1 609 92A 3N6 | (7.11.17)

 Do not attach a saw chain, woodcarving blade, seg-

mented diamond wheel with a peripheral gap greater

than 10 mm or toothed saw blade. Such blades create

frequent kickback and loss of control.

 Do not “jam” the wheel or apply excessive pressure. Do

not attempt to make an excessive depth of cut. Over-

stressing the wheel increases the loading and susceptibili-

ty to twisting or binding of the wheel in the cut and the pos-

sibility of kickback or wheel breakage.

 When wheel is binding or when interrupting a cut for

any reason, switch off the power tool and hold the pow-

er tool motionless until the wheel comes to a complete

stop. Never attempt to remove the wheel from the cut

while the wheel is in motion otherwise kickback may

occur. Investigate and take corrective action to eliminate

the cause of wheel binding.

 Do not restart the cutting operation in the workpiece.

Let the wheel reach full speed and carefully re-enter

the cut. The wheel may bind, walk up or kickback if the

power tool is restarted in the workpiece.

 Support panels or any oversized workpiece to minimize

the risk of wheel pinching and kickback. Large work-

pieces tend to sag under their own weight. Supports must

be placed under the workpiece near the line of cut and near

the edge of the workpiece on both sides of the wheel.

 Use extra caution when making a “pocket cut” into ex-

isting walls or other blind areas. The protruding wheel

may cut gas or water pipes, electrical wiring or objects that

can cause kickback.

Additional safety warnings

Wear safety goggles.

Wear a dust respirator.

 Use clamps or another practical way to secure and sup-

port the workpiece to a stable platform. Holding the

work by your hand or against the body leaves it unstable

and may lead to loss of control.

 Wear hearing protection, safety goggles, dust mask

and gloves. As dust mask, use at least a particle filter-

ing half mask of filter class FFP 2.

 Use suitable detectors to determine if utility lines are

hidden in the work area or call the local utility company

for assistance. Contact with electric lines can lead to fire

and electric shock. Damaging a gas line can lead to explo-

sion. Penetrating a water line causes property damage or

may cause an electric shock.

 Do not touch the cutting disc after working before it

has cooled. The cutting disc becomes very hot while work-

ing.

 When working with the machine, always hold it firmly

with both hands and provide for a secure stance. The

power tool is guided more secure with both hands.

Products sold in GB only: Your product is fitted with a

BS 1363/A approved electric plug with internal fuse (ASTA

approved to BS 1362).

If the plug is not suitable for your socket outlets, it should be

cut off and an appropriate plug fitted in its place by an author-

ised customer service agent. The replacement plug should

have the same fuse rating as the original plug.

The severed plug must be disposed of to avoid a possible

shock hazard and should never be inserted into a mains sock-

et elsewhere.

Product Description and Specifica-

tions

Read all safety warnings and all instruc-

tions. Failure to follow the warnings and in-

structions may result in electric shock, fire

and/or serious injury.

Intended Use

With firm support of the base plate and using the blade guard,

the machine is intended for horizontal cutting or slotting of

mainly mineral materials such as marble without the use of

water. The machine is not intended for cutting in wood, plas-

tic or metal.

Product Features

The numbering of the product features refers to the illustra-

tion of the machine on the graphics page.

1 On/Off switch

2 Lock-on button for On/Off switch

3 Cutting-depth scale

4 Wing bolt for cutting depth preselection

5 Blade guard

6 Diamond cutting disc*

7 Direction-of-rotation arrow for grinding spindle

8 Base plate

9 Handle (insulated gripping surface)

10 Drive spindle

11 O-ring

12 Mounting flange

13 Clamping flange

14 Ring spanner

15 Clamping bolt

16 Hex key

*Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

OBJ_BUCH-3076-004.book Page 7 Tuesday, November 7, 2017 10:52 AM
