2

GB

Installation

! This instruction manual should be kept in a safe

place for future reference. If the washer-dryer is

sold, transferred or moved, make sure that the

instruction manual remains with the machine so

that the new owner is able to familiarise himself/

herself with its operation and features.

! Read these instructions carefully: they con-

tain vital information relating to the safe instal-

lation and operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the washer-dryer from its packa-

ging.

2. Make sure that the washer-dryer has not

been damaged during the transportation

process. If it has been damaged, contact the

retailer and do not proceed any further with

the installation process.

3. Remove the 4 pro-

tective screws (used

during transportation)

and the rubber wa-

sher with the cor-

responding spacer,

located on the rear

part of the appliance

(see figure).

4. Close off the holes using the plastic plugs

provided.

5. Keep all the parts in a safe place: you will

need them again if the washer-dryer needs to

be moved to another location.

! Packaging materials should not be used as

toys for children.

Levelling

1. Install the washer-dryer on a flat sturdy floor,

without resting it up against walls, furniture

cabinets or anything else.

2. If the floor is not

perfectly level, com-

pensate for any une-

venness by tightening

or loosening the

adjustable front feet

(see figure); the angle

of inclination, measu-

red in relation to the

worktop, must not

exceed 2°.

Levelling the machine correctly will provide

it with stability, help to avoid vibrations and

excessive noise and prevent it from shifting

while it is operating. If it is placed on carpet or

a rug, adjust the feet in such a way as to allow

a sufficient ventilation space underneath the

washer-dryer.

Connecting the electricity and

water supplies

Connecting the water inlet hose

1. Connect the inlet

hose by screwing it to

a cold water tap using

a 3/4 threaded con-

nection (see figure).

Before performing the

connection, allow the

water to run freely un-

til it is perfectly clear.

2. Connect the inlet

hose to the washer-

dryer by screwing it

onto the correspon-

ding water inlet of the

appliance, which is

situated on the top

right-hand side of the

rear part of the ap-

pliance (see figure).

3. Make sure that the hose is not folded over

or bent.

! The water pressure at the tap must fall within

the range of values indicated in the Technical

data table (see next page).

! If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.
