2

GB

Installation

! This instruction manual should be kept in a safe

place for future reference. If the washer dryer is

sold, transferred or moved, make sure that the

instruction manual remains with the machine so

that the new owner is able to familiarise himself/

herself with its operation and features.

! Read these instructions carefully: they contain

vital information relating to the safe installation

and operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the washer dryer from its packaging.

2. Make sure that the washer dryer has not been

damaged during the transportation process. If it

has been damaged, contact the retailer and do not

proceed any further with the installation process.

3. Remove the 4 pro-

tective screws (used

during transportation)

and the rubber washer

with the corresponding

spacer, located on the

rear part of the applian-

ce (see figure).

4. Close off the holes using the plastic plugs

provided.

5. Keep all the parts in a safe place: you will

need them again if the washer dryer needs to

be moved to another location.

! Packaging materials should not be used as

toys for children.

Levelling

1. Install the washer dryer on a flat sturdy floor,

without resting it up against walls, furniture ca-

binets or anything else.

2. If the floor is not per-

fectly level, compensa-

te for any unevenness

by tightening or loo-

sening the adjustable

front feet (see figure);

the angle of inclination,

measured in relation to

the worktop, must not

exceed 2°.

Levelling the machine correctly will provide it with

stability, help to avoid vibrations and excessive

noise and prevent it from shifting while it is ope-

rating. If it is placed on carpet or a rug, adjust

the feet in such a way as to allow a sufficient

ventilation space underneath the washer dryer.

Connecting the electricity and wa-

ter supplies

Connecting the water inlet hose

1. Connect the supply

pipe by screwing it to

a cold water tab using

a ¾ gas threaded con-

nection (see figure).

Before performing the

connection, allow the

water to run freely until

it is perfectly clear.

2. Connect the inlet

hose to the washer dr-

yer by screwing it onto

the corresponding wa-

ter inlet of the applian-

ce, which is situated on

the top right-hand side

of the rear part of the

appliance (see figure).

3. Make sure that the hose is not folded over

or bent.

! The water pressure at the tap must fall within

the values indicated in the Technical details table

(see next page).

! If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.
